ESCORTS Digmax II 4WD
  • +2 Images

ESCORTS Digmax II 4WD

0(0 Reviews)

ESCORTS Digmax II 4WD is available in the India market with an ex-showroom price of ₹25.00 Lakh. ESCORTS Digmax II 4WD comes with 400 Nm,0.26.

₹25.00 Lakh*

View Price Breakup

EMI starts @

₹46,706/Month*

Ex-showroom price in

ESCORTS Digmax II 4WD

EMI starts @

₹46,706/Month*

  • Digmax II 4WD
  • Price
  • Variants
  • Images
  • Specs
  • Reviews
  • Q&A
  • Videos
  • EMI
  • Brochure

ESCORTS Digmax II 4WD Construction Equipments Features

  • 400 Nm
    Maximum Torque
  • 0.26
    Bucket Capacity

ESCORTS Digmax II 4WD Construction Equipments Overview

ESCORTS Digmax II 4WD Construction Equipments Engine

ESCORTS Digmax II 4WD is powered by 400 Nm and 0.26

ESCORTS Digmax II 4WD Latest Price in India 2025

ESCORTS Digmax II 4WD is available in India starting from ₹25.00 Lakh

ESCORTS Digmax II 4WD Alternatives & Competitors

Main rival Construction Equipments of ESCORTS Digmax II 4WD are JCB 3DX, JCB 4DX, ACE AX-124 4WD, BOBCAT B900, BULL HD 100 and CAT 424

Keep reading to explore more about ESCORTS Digmax II 4WD's updated specs, latest prices, horsepower, genuine user reviews, exclusive images, best offers near you, Construction Equipments dealers.

ESCORTS Digmax II 4WD Variant Price Range
Base ₹25.00 Lakh

Read More

ESCORTS Digmax II 4WD Price List Variants

ESCORTS Digmax II 4WD Images

  • ESCORTS Digmax II 4WD

    ESCORTS Digmax II 4WD

  • ESCORTS Digmax II 4WD

    ESCORTS Digmax II 4WD

ESCORTS Digmax II 4WD Specifications

  • Engine
  • Loader General Dimension
  • Backhoe Loader Dimension
  • Overall Dimension & Weight
  • Hydraulic system
  • Service Capacities
  • Axle
  • Steering
  • Brakes
  • Tyre
  • Power Train
  • General
Engine
Model4R1190NA
CompliantBS-IV
Air Intake TypeWater Cooled
Gross Power75 hp
Maximum Torque400 Nm
Loader General Dimension
Dump Height3000 MM
Load Over Height3510 MM
Hinge Pin Height3700 MM
Hinge Pin Forward Reach430
Reach At Ground1570
Max Reach At Full Height Bucket Dumped1220
Below Ground Level Dig Depth130
Rollback At Ground45 deg
Dump Angle45 Deg
Bucket Capacity Std1.2
Bucket Breakout Force6425 Kgf
Loader Arm Breakout Force5777 Kgf
Max Pay Load1980 kg
Backhoe Loader Dimension
Max Dig Depth4800 mm
Reach Ground Level To Rear Wheel Center6970
Reach At Full Height To Slew Center2230
Max Working Height6300
Max Load Over Height4390
Bucket Capacity0.26
Bucket Capacity Backhoe0.26
Bucket Rotation187 Degree
Dipper Tear Out Force3250 kgf
Max Lift Capacity1554 Kg
Overall Dimension & Weight
Max Operating Weight8400
Transport Length6280
Width Over Bucket2380MM
Track Width Rear1750 MM
Track Width Front1870 MM
Wheelbase2140 MM
Minimum Ground Clearance350 MM
Height To Top Of Cabin2880
Hydraulic system
Pump TypeAxial Piston Pump
Pump Flow117 lpm
Relief Pressure225 bar
Service Capacities
Engine Oil11.5
Rear Axle17.1 Ltr.
Fuel Tank134 litres
Coolant15 Ltr.
Hydraulic Oil110
Transmission Oil Capacity16.5 Ltr
Axle
Rearear Drive Axle With rigidly mounted to chassis
FrontFront Drive and Steer Axle
Front Oscillation±12 Degree
Steering
TypeHydrostatic Power Steering
Pressure120 Bar
Brakes
ServiceHydraulically actuated dual line, self adjusting, oil immersed, multi disc type on rear axle
ParkingHand-operated caliper disc brakes
Tyre
Hd Rear Optional14x25 - 20 PR
Standard Front9.00 x 16 - 16PR
Standard Rear16.9 x 28 - 12PR
Power Train
Transmission Make And ModelSyncro shift reversing shuttle transmission
General
CategoryBackhoe Loader
Forward5.3/8.5/18.5/36.6
Reverse4.6/7.0/ Not recommended
