ACE Phantom 4WD N Construction Equipments Specs & Features

  • 400 Nm
    Maximum Torque
  • 0.3
    Bucket Capacity

ACE Phantom 4WD N Construction Equipments Overview

ACE Phantom 4WD N Construction Equipments Engine

ACE Phantom 4WD N is powered by 400 Nm and 0.3

ACE Phantom 4WD N Latest Price in India 2025

ACE Phantom 4WD N is available in India starting from 0

ACE Phantom 4WD N Alternatives & Competitors

Main rival Construction Equipments of ACE Phantom 4WD N are JCB 3DX, JCB 4DX, ACE AX-124 4WD, BOBCAT B900, BULL HD 100 and CAT 424

Keep reading to explore more about ACE Phantom 4WD N's updated specs, latest prices, horsepower, genuine user reviews, exclusive images, best offers near you, Construction Equipments dealers.

ACE Phantom 4WD N Variant Price Range
Base

Read More

ACE Phantom 4WD N Price List Variants

ACE Phantom 4WD N Images

  • ACE Phantom 4WD N

    ACE Phantom 4WD N

ACE Phantom 4WD N Specifications

  • Engine
  • Loader General Dimension
  • Backhoe Loader Dimension
  • Overall Dimension & Weight
  • Hydraulic system
  • Service Capacities
  • Axle
  • Steering
  • Brakes
  • Tyre
  • Electrical System
  • General
Engine
ModelKILOSKAR 4R1040TA
CompliantBS-III
Air Intake TypeTurbocharged Water Cooled
Gross Power96 hp
Maximum Torque400 Nm
Loader General Dimension
Dump Height2960 MM
Load Over Height3350
Hinge Pin Height3630
Reach At Ground1770 MM
Max Reach At Full Height1220 MM
Max Reach At Full Height Bucket Dumped1220
Below Ground Level Dig Depth80 MM
Rollback At Ground44 Deg
Dump Angle45 Deg
Bucket Capacity Std1.1
Bucket Breakout Force5200 Kgf
Max Pay Load1900 kg
Backhoe Loader Dimension
Bucket Capacity0.3
Max Lift Capacity1900
Overall Dimension & Weight
Max Operating Weight8040
Minimum Ground Clearance350 MM
Hydraulic system
Pump Flow118 lpm
Service Capacities
Engine Oil11.5
Rear Axle3 Ltr.
Fuel Tank150 ltrs
Coolantwater cooled
Hydraulic Oil90
Axle
RearRigid axle with CARRARO planetary drive
FrontDrive & Steer Axle, centrally pivoted
Steering
TypeHydrostatic steering for reliability and better control
Brakes
ServiceHydraulically Actuated Disc Brakes
ParkingMechanically actuated disc brakes for parking
Tyre
Standard Front9.00 x 16 – 16 PR
Standard Rear16.90-28-12 PR
Electrical System
Battery12 V
General
CategoryBackhoe Loader
