Comparison For JCB 3DX-vs-MAHINDRA Earthmaster SX IV
Confused between JCB 3DX and MAHINDRA Earthmaster SX IV ? Wondering whether you should spend that hard earned money on JCB 3DX and MAHINDRA Earthmaster SX IV? Don't Worry! We are here to help you choose between these two models. Talking about JCB 3DX, it has been priced at Rs ₹35.00 Lakh. On the other hand, MAHINDRA Earthmaster SX IV will cost you more than JCB 3DX. MAHINDRA Earthmaster SX IV comes with a price tag of Rs ₹31.00 Lakh.
Check the details
Check the detailed comparison for the models below on the basis of features, comfort, power, transmission, suspension and more.
| Key Highlights | JCB 3DX | MAHINDRA Earthmaster SX IV |
|---|---|---|
| EX-Showroom Price | ₹35.00 Lakh | ₹31.00 Lakh |
Base
₹35.00 Lakh
Base
₹31.00 Lakh
Model JCB 448 VNEF 3.5 L Turbocharged Intercooled Compliant NA BS IV Displacement NA 3532 CC Gross Power 36 kW (49 hp) @ 2000 RPM 74 hp Maximum Torque NA 345 NM Dump Height 2740 MM 2708 mm Load Over Height 3320 MM 3253 mm Hinge Pin Height 3540 NA Hinge Pin Forward Reach 250 NA Reach At Ground 1420 1350 MM Max Reach At Full Height 1150 MM 1115 mm Max Reach At Full Height Bucket Dumped 780 1115 Below Ground Level Dig Depth 70 NA Rollback At Ground 45 deg NA Dump Angle 38 NA Bucket Capacity Std 1.1 1.1 Bucket Breakout Force NA 6243 kg Loader Arm Breakout Force 5300 kgf 5594 kg Max Pay Load 1800 NA Maximum Lifting Capacity 1490 NA Max Dig Depth 4770 MM 4959 mm Reach Ground Level To Swing Center 5440 5794 mm Reach Ground Level To Rear Wheel Center 6720 NA Reach At Full Height To Slew Center 2740 2774 mm Max Working Height 5970 6043 mm Max Load Over Height 4180 4131 mm Bucket Capacity NA 2.6 Bucket Capacity Backhoe 1.2 1.1 Bucket Rotation 185 deg NA Dipper Tear Out Force 3010 Kgf NA Max Lift Capacity 1490 Kg 3428 Kg Max Operating Weight 7510 7584 Transport Length 5900 NA Width Over Bucket 2350 MM NA Track Width Rear 1730 MM NA Track Width Front 1860 MM NA Minimum Ground Clearance 310 MM NA Height To Top Of Cabin 2870 MM NA Pump Type NA Fixed displacement, Gear Pump, Pump Flow 114 lpm 117 l/min Type NA Open Centre: 25 Mpa Engine Oil NA 13.7 Rear Axle 20 Ltr 17.10 Ltr Hydraulic Oil Replacement 92 Ltr NA Fuel Tank NA 140 L Coolant NA 17 Ltr Hydraulic Oil 110 100 Transmission Oil Capacity 17.5 Ltr 19.20 Ltr Rear NA Rigidly mounted drive axle, with outbound planetary final drives, driven by short drive shaft. Front NA Centrally pivoted, non-driven unbalanced type axle, with total oscillation of 16C, with remote greasing facility for the main pin. Type NA Hydraulic Power Steering Turning Circle Diameter Outside Bucket 11600 NA Turning Circle Diameter Outside Bucket Not Braked 8640 NA Service JCB ‘Q’ brakes, hydraulically actuated, dual line, self adjusting (compensated), oil immersed, multi-disc type on the rear axle, well protected from dirt, water etc. requiring no maintenance. Operated Hydraulically actuated, self adjusting, maintenance free, oil immersed multi-disc, on the rear axle, operated by independent foot pedals, joined together for normal operation. Parking Hand operated, disc brakes on rear axle input disc. Hand operated mechanically actuated caliper type brake Standard Front 9 x 16 - 16 PR NA Standard Rear 16.9 x 28 - 12 PR NA Transmission Make And Model NA Four Speed 4 Forward, 4 Reverse Category Backhoe Loader Backhoe Loader Power 49 HP NA Bucket Capacity 0.26 cu.m NA Maximum Torque 240 Nm NA
